Led Motion Sensor 220V 12V Automatic Infrared Pir Infrared Detector 180 Degree Rotation Outdoor Timer Switch Motion Sen

Led Motion Sensor 220V 12V Automatic Infrared Pir Infrared Detector 180 Degree Rotation Outdoor Timer Switch Motion Sen

$22.95
2/7
description
product reviews



Feature:
The infrared motion sensor is energy-saving automatic lighting switch, it adopts high sensitivity detector, integrate circuit.
With wide detection range made up of up and down, left and right service field.
It utilizes human motion infrared rays as control signal sources, when one enters the detection field, it will start the controlled load at once.
The ambient light of PIR sensor switch could be adjusted according to your desire.
Time-delay Adjustable: It can be set according to your desire, the minimum is 5sec, the maximum is 10min.
180 degree sensing angle, 12 minus or plus 2m sensing distance, easy and convenient to use.
It's widely used in intelligent lighting, easy installation on doorways, corridors, elevators, balconies, bathrooms, mirrors, wardrobes, cabinets, warehouses, basements, garages, etc.

Specification:

Power source: 220-240V AC
Detection angle: 180°
Detection distance: 12±2m
Power frequency: 50Hz
Ambient light: 3-2000LUX(adjustable)
Rated load: 1200W (Resistive load like incandescent lamp)
300W (inductive load such as LED, energy saving lamp )
Working temperature: -20 -40℃
Time-delay: min: 10sec ± 3sec
Max: 8min ± 2min
Power consumption: 0.45W (work), 0.1W (static)
Working humidity: <93%RH
Installation height:1.8m-2.5m
Detection motion speed: 0.6-1.5m/s
IP Grade: IP44(Suitable for indoor and outdoor)
Color: Black, White (Optional)

Package Included:
1 x 180° Infrared Motion Sensor Switch
1 x Manual
