80Cc 2 Stroke Bicycle Gas Engine Kit For Diy Electric Bicycle Mountain Pocket Bike Complete Engine Set Motor Kit Silver
pls notes we have the EU/US/AU/UK local warehouse,we will sent you the fast shipping,let you enjoyShopping!
PLS NOTE: Exhaust Muffler of 80CC Engine kit will send black or silver color randomly!!
It can reach 38 km / h. It almost runs as fast as a motorcycle or scooter, making your outdoor trip more convenient. This engine kitfits most 26 "or 28" motorcycles with a V-frame.
- A complete engine kit to convert your bike
- Rugged metal body for durability
- Super efficient fuel, consuming only 2.5 liters of fuel per 100 km
- Fast and smooth, it can accelerate up to 38km / h
- It comes with all the necessary hardware for easy installation
- Suitable for most 26 "and 28" motorcycles, such as mountain bikes, road bikes, cruises, helicopters.
- Engine mode: Single cylinder, air cooling, 2 stroke
- Bore and stroke: 47mm and 40mm
- Rated power: 2.5Kw / 5000r / min (3 horsepower / 5000r / min)
- Maximum power: 3.5Kw / 6000r / min (5-6 horsepower / 6000r / min)
- Power Mode: CDI
- Chain Model: 415
- Chain Length: 110 links
- Compression ratio: 6: 01
- Driving Ratio: 18: 01
- Fuel Type: No.90
- Tank Capacity: 2L
- Speed limitation: 38km / hour
- Lubrication Oil: 2-stroke gasoline engine oil (or oil for 10W / 40.10W / 30)
- Mixing ratio of fuel and engine oil: 16: 1 for new assemblies, 20: 1 after running 500 km
- Type of ignition plug: Z4C 14MM
- Oil volume Consumption: 2.5L / 100km
- Clutch Type: friction / dry plate
- Cooling mode: Natural air cooling
- Start method: Electric/Kick
- 1x Black/Sliver 80cc 2-stroke engine(Depending on your choice)
- 1x Pinion clamp with hardware
- 1x Exhaust Muffler
- 1x button clutch
- 1x heavy chain
- 1x bearing / brake chain tensioner
- 1x Carburetor
- 1x CD ignition coil
- 1x Lock switch (on the throttle)
- 1x Chain Protector
- 1x Spark Plug
- 1x Black fuel tank with mounting brackets
- 1x Exhaust Pipe Clamp
- 1x plug removal tool
- 1x Manual
All necessary mounting brackets, gaskets and hardware
Please note that our engine kit has been replaced with a New version. The cylinder and cylinder head of the New version are different from the Old version, but the functions are the same. Other accessories have also been replaced with better quality!!!
- The kit includes all the parts and instructions necessary to convert your bike.
- Please note that the engine will use a mixture of gasoline and oil. The oil is used as a lubricant. Without it, engine performance and longevity will be reduced. See the manual for more information, including gasoline / oil ratios.
