Technical parameters

Operating voltage: 12V

Operating current: ≤12mA

Remote control distance: 50-100m (sensitivity of receiving device is -100dbm in open environment)

Modulation mode: ASK modulation

Number of keys: 4

Material: ABS.

Color: Black

Size: 6.8 x 1.6 x 1.5 cm

Operating frequency: 433mhz

Battery type: 12v 27A (inclusive)

Copy chip type reference: Learning code (HS1527, EV1527, HT6P20B, etc.), fixed code (HS2260, HS2260, PT2260, SC2262, etc.)

1. Clear code:

Press the two button indicators on the upper row of the remote control at the same time and flash once for about 2 seconds, which means that the clearing is successful. After clearing, press the four buttons of the remote control and the indicator light flashes for a while and then goes out.

2. Remote control copy method: hold the copy type remote control to copy keys don't let go, and at the same time hold down the corresponding to be copied the remote control to copy the keys don't let go, near two remote controls, to about 3 seconds, lights never copy the remote control to slow flash to flash, at this time, let go, try click this button and goes on to say to copy success. The same goes for other key copies.

3 Remote control restoration function: If the code is cleared by mistake, press the upper and lower buttons (3 and 4 buttons) as shown in the picture for 2 seconds, and the light flashes, indicating that the internal code is restored successfully.

Technical parameters

1. Working voltage: 3V

2, working current: 10mA

3, working frequency: 433MHz

4, transmission power: +13dbm

5. Remote control distance: 50M (measured in open field)

6. Working environment: -15/+75 degrees Celsius

Instructions:

In the distribution of remote control to confirm their original remote control is normal use. Also be aware of the transmission frequency of the remote control.

1. Clear code:

Press the two button indicators on the upper row of the remote control at the same time and flash once for about 2 seconds, which means that the clearing is successful. After clearing, press the four buttons of the remote control and the indicator light flashes for a while and then goes out.

2, copy:

Put the original remote control and the copy remote control side by side (it is better to hold the copy remote control in the right hand), press the two remote control arbitrary keys at the same time, the copy remote control indicator flash means that the replication is successful. It takes only 1 second to replicate successfully. Copy the other three keys in the same way.

3. Recovery:

If the useful code is cleared by misoperation, press the two buttons in the lower row of the remote control at the same time before copying other remote controls, and the indicator blinks quickly for 2 seconds, then the recovery is successful.

Description:

This device is a wireless remote control key, with super functions, for your daily life to bring a lot of convenience. Support remote wireless control of your rolling shutter door, garage door and other remote control devices within 50m (free space). We bring you a new remote control experience, you can not miss.

Features:

* Support universal learning code chip (1527), such as PT1527, EV1527, etc. Compatible with most 1527 remote relay panels.

* Stable circuit, high precision, high performance, personalized, humanized design, bring you a lot of convenience.

* Imported high frequency triode, transmission power 13dBm.

* Easy to use: Easy to install and use, the 4-channel remote control system lets you control your device, car, home or garage.

* Wide use: very suitable for controlling electric doors, telescopic doors, garage doors, cars, motorcycles, electric curtains and other remote control equipment.

Glasses:

Model Number: KT01-4.

Material: metal and PVC

Product Type: Learning code (1527) remote control key.

Rf frequency: 433 MHz

Compatible channel: four channels.

Encoding type: Learning code (1527)

Modulation system: ASK.

Operating voltage: DC 12V.

Operating current: <25mA.

Transmitting power: + 13dbm.

Frequency wind: + 0.2 MHz or -0.2 MHz.

Transmission distance: 50m (free space).

Color: Black

Package size: 5.5 * 3.0 * 1.0cm / 2.16 * 1.18 * 0.39oz.

Technical parameters

1. Working voltage: DC3V

2, working current: ≤15mA

3, static current: 0mA

4, working frequency: 315MHZ/433MHZ

5. Remote control distance: 50M (in open environment)

6, code mode: intelligent copy type

7, working environment: -15*75 degrees Celsius

8. Modulation mode: ASK amplitude modulation

9, inch: 56.36*31.58*11.03mm

Instructions before use:

1. This remote control is not universal. Copy PT2260, PT2262, PT2264, PT2240, SC2260, SC2262, CS5211, HX2260, HX2262, HS2262, EV1527, HS1527, HS2260, FP527, HX1527, SMC918, AX5026 , SMC926, etc., chip model prefix of different manufacturers may be different, just for the digit part. Common copy objects are electric door remote control, garage door remote control, telescopic door remote control, translation door remote control, road gate remote control, shutter door remote control, remote control used in the alarm, all kinds of fixed code, learning code remote control.

2, in the distribution of remote control to confirm their original remote control can be used normally. In addition, we should be clear about the transmission frequency of the remote control, usually we do not know what the transmission frequency of the remote control is, please open your remote control for reference

Specific operation methods:

1. Clear code:

Press the two button indicators on the upper row of the remote control at the same time and flash once for about 2 seconds, which means that the clearing is successful. After clearing, press the four buttons of the remote control and the indicator light flashes for a while and then goes out.

2, copy:

Put the original remote control and the copy remote control side by side (it is better to hold the copy remote control in the right hand), press the two remote control arbitrary keys at the same time, the copy remote control indicator flash means that the replication is successful. It takes only 1 second to replicate successfully. Copy the other three keys in the same way.

3. Recovery:

If the useful code is cleared by misoperation, press the two buttons in the lower row of the remote control at the same time before copying other remote controls, and the indicator blinks quickly for 2 seconds, then the recovery is successful.

Technical parameters

1. Working voltage: 3V

2, working current: 10mA

3, working frequency: 315MHz/433MHz

4, transmission power: +13dbm

5. Remote control distance: 100M (measured in open field)

6. Working environment: -15/+75 degrees Celsius

Instructions:

1. This remote control is not universal. Copy PT2260, PT2262, PT2264, PT2240, SC2260, SC2262, CS5211, HX2260, HX2262, HS2262, EV1527, HS1527, HS2260, FP527, HX1527, SMC918, AX5026 , SMC926, etc., chip model prefix of different manufacturers may be different, just for the digit part. Common copy objects are electric door remote control, garage door remote control, telescopic door remote control, translation door remote control, road gate remote control, shutter door remote control, remote control used in the alarm, all kinds of fixed code, learning code remote control.

2, in the distribution of remote control to confirm their original remote control can be used normally. In addition, it is necessary to know the transmission frequency of the remote control!

1. Clear code:

Press the two button indicators on the upper row of the remote control at the same time and flash once for about 2 seconds, which means that the clearing is successful. After clearing, press the four buttons of the remote control and the indicator light flashes for a while and then goes out.

2, copy:

Put the original remote control and the copy remote control side by side (it is better to hold the copy remote control in the right hand), press the two remote control arbitrary keys at the same time, the copy remote control indicator flash means that the replication is successful. It takes only 1 second to replicate successfully. Copy the other three keys in the same way.

3. Recovery:

If the useful code is cleared by misoperation, press the two buttons in the lower row of the remote control at the same time before copying other remote controls, and the indicator blinks quickly for 2 seconds, then the recovery is successful.

Description:

The device is a wireless remote control key (transmitter), with super functions, for your daily life to bring a lot of convenience. Remote and wireless support. Control garage doors, electronic doors, electrical appliances and other remote control devices within 100m (free space). We bring you a new remote control experience, you can not miss.

Features:

* Only support learning code 1527: this remote control only support the receiver (not included) learning code (1527). Remote controls compatible with these chips: PT1527, EV1527, SCT527, HS1527, SCL1527, FP1527, EV1527. Compatible with most 1527 remote relay receiver modules... If the remote is lost, buy one and pair it with the receiver.)

* strong rf signal: encrypted rf signals can pass through walls without interference problems, effective remote control range up to 100m / 330ft (free space).

* Customized design: rf technology and stable circuit, high efficiency, high precision, personalized, humanized design, bring you a lot of convenience.

* Easy to use: No wires, no apps, the 4-channel Remote key (transmitter) lets you easily control your device, car, home or garage.

* Wide use: it can be connected with electric lock, lamp, fan, window, curtain, motor, automobile, lifting machinery, motor control, elevator control or other electrical appliances. You can also remotely unlock doors, turn off lights, open or close curtains, etc.

Notes:

1. This remote control only supports receiver learning code (1527).

2. This remote controller cannot be programmed.

3. If you only buy the launcher, it will not work properly. They are part of remote control system and need to cooperate with remote relay receiving module to achieve control.

Glasses:

Model: KT19-4.

Working rf frequency: 433MHz.

Coding system: 1527 learning code.

Working voltage: 6V DC.

Operating current: 15mA.

Modulation system: ASK.

Wireless operating distance: 100m (free space).
